1P 2P 3P 4P DZ47 3A-125A AC 230V 400V C Type Mini Circuit Breaker MCB Short Overload Protector Din Rail Mount Breaking

The breaker is CE certified, ensuring compliance with safety standards, and supports a wide range of electric currents from 3A to 125A, offering flexibility for different load requirements. Made from high fire-retardant and shockproof plastics, this product ensures durability and safety in critical environments.

Description:
Designed with a rated voltage of 220/380V, this circuit breaker is available in 1P, 2P, 3P, and 4P configurations, making it suitable for various single-phase and multi-phase applications. With a breaking current of 6000A and 10000A, it ensures a high level of protection.

Specifications:
Poles:1P,2P,3P,4P
Rated Current (In) : 3A-125A
Rated Voltage (Ue):1P:230/400V~;2P-4P:400V of 1P:240/415V~;2P-4P:415V
Working Frequency:50/60Hz
Tripping Curves:B、C、D
Breaking Capacity:3A-63A 6kA / 80A-125A 10kA
Mechanical Life:20000 time
Electrical Life:6000 time
As Per Instantaneous Release Type:C type (5ln~10ln)

Package list:
1* Mini Circuit breaker

Note:
1. Please allow 1-5mm error due to manual measurement.
2. Due to the difference between different monitors, the picture may not reflect the actual color of the item.
